What Is MIDI and How Does the Jamstik Use it?

The acronym MIDI stands for “Musical Instrument Digital Interface.” In the simplest explanation, MIDI is a language (technically speaking, it’s a protocol) that allows digitally-controlled musical instrument devices to communicate to each other. MIDI has been around since the early 1980’s. It was primarily used with synthesizers and sequencers, but quickly got implemented on all kinds of musically-related gear (drum machines, mixers, drum pads, synchronization boxes, etc.)

MIDI controller

Like QWERTY for Music

The most common misconception about MIDI is that MIDI passes audio from one instrument to the next. It’s easy to confuse what’s really going on. When you play a note from a MIDI controller and you hear sounds from a MIDI synth (or a Mac or an iPad/iPhone), you might think that the “sound” is in the controller, but that’s not what’s happening. The easiest analogy to understanding the relationship between MIDI controllers and MIDI synths (or software instruments controlled by MIDI in a Mac or iPad/iPhone) is to think about how a Bluetooth mouse or keyboard interacts with a Mac or iPad/iPhone. The Bluetooth keyboard just sends the keystroke info over to the Mac or iPad/iPhone; It doesn’t magically move the Mac or iPad/iPhone processing power over to the keyboard. The Bluetooth keyboard just “controls” the software on the platform. With MIDI, the controller is just sending the “keystrokes” over to the iPad/iPhone or Mac. (Okay, there’s a little more going on than keystrokes, but not too much more…) Audio (sound) isn’t passed over MIDI in the traditional sense.

In the context of using the jamstik (a MIDI guitar controller), your fretting and picking activity generates MIDI events that the Mac/iPad/iPhone recognizes and connects to the appropriate MIDI software responsible for making sounds. The jamstik is like a QWERTY keyboard typing letters into a sonic version of Text Edit.

MIDI is a little more complex than that illustration, but if you can wrap your head around that concept you can follow the rest of the details.

Breakdown of a MIDI event from a jamstik

At the most basic of levels, it works like this:

  • When you fret a C note on the third fret of the A string, the jamstik sends a MIDI message that has a ‘Note-On’ command with a note number (C2) and a velocity value (which is generated by how hard you picked the string).
  • That message arrives at the receiving software communicating which note to play (C2) and how “loud” to sound the individual note (velocity value of 127 because you really picked that C hard.)
  • When you lift your finger off the third fret of the A string, the jamstik sends a Note-Off message. (Yeah, MIDI works in little incremental steps -- Note-Ons and Note-Offs. A ‘Note-On’ event tells the software to turn the C2 sound on, the ‘Note-Off’ event tells the software to turn the C2 sound off. If the Note-off isn’t transmitted, the C2 will stay on until the ‘Note-Off’ is sent.)
  • Each string and fret position on the jamstik sends a specific note number.  (If you switch octaves using the D-pad, the jamstik is working from a different table of note numbers.)

Jamstik MIDI guitar

MIDI Channels

Note “events” (note numbers with corresponding velocities) are transmitted on MIDI Channels. Back in the 1980’s when MIDI was transmitted on cables (how primitive!), you needed to be able to distinguish the difference between MIDI events you wanted to send to Synth A or Synth B. So, using assignable channels on your MIDI devices was a way keep your messages coming and going to the right synths. Each MIDI port (or cable) could address 16 MIDI channels. (This still holds true. If you see a physical 5 pin DIN MIDI connector, the maximum number of MIDI Channels that port can address is 16.) If I assigned Synth A to MIDI Channel 1 and Synth B to MIDI Channel 2, the messages on a shared MIDI cable wouldn’t get confused between Synths A & B.

Back in the early days of MIDI guitar controllers, the convention was established that each string would transmit on its own MIDI Channel. There are a number of good reasons for this which I’ll spare you the details of, but the jamstik follows this convention in its default state. The Low E string is on Channel 6, the A is on channel 5, the D is on channel 4, the G is on 3 channel, the B is on channel 2, and the high E string is on Channel 1.

Since MIDI operations have largely moved into the realm of virtual connections in software, the 16-channel limitation isn’t bound to the cable anymore. However, all MIDI software generally still follows the same “16-channels per port” connection. As this applies to the jamstik it’s not super relevant, but as you begin to delve deeper into different MIDI apps and software it will be important to remember that the jamstik creates its own virtual port via ZFi. Some software requires that you identify and select a virtual port, and as this happens over ZFi it will always be your “MyJamstikXXXX” ID from the WiFi browser.

Continuous Controllers

MIDI does have a number of other commands commonly in use that aren’t tied to note events. They are called “Continuous Controllers.” Pitch Bend messages, which get sent when you bend a jamstik string, don’t require a note event to be transmitted with and is a part of the Continuous Controller family. Modulation messages are also Continuous Controllers. Volume (not to be confused with velocity) is a Continuous Controller, as well.
